TI LMZM33603RLRR

Small Power Module

ISO14001 ISO9001 IATF16949 ISO13485 DUNS

Brands: Texas Instruments

Mfr.Part #: LMZM33603RLRR

Datasheet: LMZM33603RLRR Datasheet (PDF)

Package/Case: B3QFN (RLR)-18

Product Type: DC DC Converters

RoHS Status:

Stock Condition: 4,543 pcs, New Original

Warranty: 1 Year Ovaga Warranty - Find Out More

Quick Quote

Please submit RFQ for LMZM33603RLRR or email to us: Email: [email protected], we will contact you within 12 hours.

LMZM33603RLRR General Description

The LMZM33603RLRR power module represents the pinnacle of power supply technology, offering a combination of performance, efficiency, and safety features that are unmatched in the industry. Its wide input and output voltage ranges make it a versatile solution for various applications, while the integrated inductor and protection mechanisms simplify the design process and ensure the longevity of the system. Whether you're designing a new industrial machine or upgrading a telecommunications network, this power module from Texas Instruments is sure to meet and exceed your expectations

Features

  • High-efficiency power conversion with low noise
  • Wide input voltage range ensures flexibility
  • This module has integrated shielded inductor and controller

Application

  • Compact power solution
  • Reliable performance
  • Suitable for various uses

Specifications

Parameter Value Parameter Value
Maximum Continuous Drain Current (A) 3 Vin (min) (V) 4
Vin (max) (V) 36 Vout (min) (V) 1
Vout (max) (V) 18 Soft start Fixed
Features EMI Tested, Enable, Frequency synchronization, Power good Operating temperature range (°C) -40 to 105
Iq (typ) (mA) 8.5 Regulated outputs (#) 1
Switching frequency (max) (kHz) 1200 Switching frequency (min) (kHz) 200
Duty cycle (max) (%) 90 Regulator Topology Buck, Inverting Buck-Boost, Synchronous Buck
Manufacturer Type Module
