8-bit Microcontrollers - MCU 8-bit Ultralow MCU 2kb UFQFPN 20 pin

Ovaga Certification

Brands: STMicroelectronics, Inc

Mfr.Part #: STM8L101F1U6ATR

Datasheet: STM8L101F1U6ATR Datasheet (PDF)

Package/Case: UFQFPN 3X3X0.6 20L 0

Product Type: Embedded Processors & Controllers

RoHS Status:

Stock Condition: 2874 pcs, New Original

Add To Bom

Quick Quote

Please submit RFQ for STM8L101F1U6ATR or email to us: Email: [email protected], we will contact you within 12 hours.

STM8L101F1U6ATR General Description

Main microcontroller featuresSupply voltage range 1.65 V to 3.6 VLow power consumption (Halt: 0.3 µA, Active-halt: 0.8 µA, Dynamic Run: 150 µA/MHz)STM8 Core with up to 16 CISC MIPS throughputTemp. range: -40 to 85 °C and 125 °CMemoriesUp to 8 Kbytes of Flash program including up to 2 Kbytes of data EEPROMError correction code (ECC)Flexible write and read protection modesIn-application and in-circuit programmingData EEPROM capability1.5 Kbytes of static RAMClock managementInternal 16 MHz RC with fast wakeup time (typ. 4 µs)Internal low consumption 38 kHz RC driving both the IWDG and the AWUReset and supply managementUltra-low power POR/PDRThree low-power modes: Wait, Active-halt, HaltInterrupt managementNested interrupt controller with software priority controlUp to 29 external interrupt sourcesI/OsUp to 30 I/Os, all mappable on external interrupt vectorsI/Os with programmable input pull-ups, high sink/source capability and one LED driver infrared outputPeripheralsTwo 16-bit general purpose timers (TIM2 and TIM3) with up and down counter and 2 channels (used as IC, OC, PWM)One 8-bit timer (TIM4) with 7-bit prescalerInfrared remote control (IR)Independent watchdogAuto-wakeup unitBeeper timer with 1, 2 or 4 kHz frequenciesSPI synchronous serial interfaceFast I2C Multimaster/slave 400 kHzUSART with fractional baud rate generator2 comparators with 4 inputs eachDevelopment supportHardware single wire interface module (SWIM) for fast on-chip programming and non intrusive debuggingIn-circuit emulation (ICE)96-bit unique ID


Parameter Value Parameter Value
feature-tradename feature-data-bus-width-bit 8
feature-interface-type I2C/SPI/USART feature-minimum-operating-supply-voltage-v 1.65
feature-maximum-operating-supply-voltage-v 3.6 feature-packaging Tape and Reel
feature-rad-hard feature-pin-count 20
feature-supplier-package UFQFPN feature-standard-package-name1 QFN
feature-cecc-qualified No feature-esd-protection
feature-military No feature-aec-qualified No
feature-aec-qualified-number feature-auto-motive No
feature-p-pap No feature-eccn-code EAR99
